Description

Extremely versatile – the TECH 700 DA digital electronic angle finder. A high-quality product made in Germany that perfectly combines three tools: angle finder, spirit level and bevel gauge. Calculate exact angles with the latest electronic measuring technology. Level components accurately with the high-quality vials. Using the locking mechanism, you can use the tool as a bevel gauge and easily transfer the measured angles onto a part. Reap the benefits of this indispensable all-rounder, which performs the work of three different tools, on a daily basis.

One tool – three functions: digital electronic angle finder, spirit level and bevel gauge

Product advantages

Electronic angle finder for quickly determining and transferring interior and exterior angles in the range from 0° – 270°.
Digital display with large digits and lighting that can be activated and dimmed.
LOCK function: locking mechanism for transferring angles reliably.
Vials which can be read easily, even when the arm is folded in.
Two particularly wide contact edges for accurate and reliable marking of angles in all positions.
REF function: allows a reference angle to be accepted, saved and then transferred to other components.
HOLD function: saves the measured value – for accurate measurements and quick transferring even in hard-to-see places.
Displays the angle bisectors at the touch of a button – ideal for quick and accurate mitre cuts.
Switches off automatically if not used for 60 minutes.
Precise measuring results with an accuracy of ± 0.1°.
Protection class IP 54.
Includes bag.
Equipment: 1 digital display, 1 horizontal vial, 1 vertical vial, 2 coated measuring surfaces.

Digital display that can be read easily and illuminated

Application examples

Especially suitable for joinery – measure and transfer angles, e.g. when installing a kitchen or when aligning other built-in furniture.
The ideal helper when laying elaborate tile motifs – transfer angles when cutting the tiles.
The perfect partner in wood construction – mark out angles in preparation for mitre cuts.
An indispensable tool in metal construction – for measuring, checking or marking angles.

Technical data

Accuracy with electronic angle measurement +/-
0.10°
Measurement accuracy in normal position
0.50 mm/m
Measurement accuracy in reverse position
0.75 mm/m
Protection class
IP 54
Number of arms
2
Max. measuring range
270°
Measuring modes
°
Operating life
120 h
